cat5e lan cable with steel messenger

Model cat5e UTP With Messenger Outdoor Cable
Conductor Size 24AWG
4*2*1/0.51mm
Conductor Material BC/CCU/CCA/OFC/CCS
Nuber Of Conductor 2P, 4P
Shiled UTP/FTP/STP/SFTP /SSTP
Flammability Grade: CMX,CM,MP,CMG,MPG,CMR,MPR
Indoor / Outdoor Single jacket / Double jacket
Messenger Yes-With Steel Messenger
Insulation Material PE , HDPE
Insulation Thickness 0.55mm
Number of pairs: 4 pairs
Pair1: Orange/White Orange Pair2: Blue/ White Blue
Pair3: Green/ White Green Pair4: Brown/White Brown
Jacket Material PVC, ROHS , LSZH ,PE
Jacket Thickness 0.92-0.95mm
DC Resistance(Max.) 9.5Ω/100m
DC Resistance Imbalance 2.50%
Working Capacitance(Max.) 5.4nF/100m
Insulation Resistance 10000MΩ.km
Transmission Velocity 65%
Operating Temperation -20 °C - +75 °C
PVC Jacket Color As client’s request.
Print Words On Cable CAT5E 4P 24AWG VERIFIED TO EIA/TIA 568B.ISO/IEC 11801 EN501 or clients' request.
Construcation Draw 200 pair 0.6mm outdoor jelly filled aerial communication cable with steel messenger
